HL7 MDM

Medical Document Management

The Medical Document Management (MDM) message provides information about new or updated notes or documents.

HL7 MDM

Contents

A
A Practical Guide to HL7 Interface Development: Building Custom Integrations for Healthcare Systems
Download the FREE Guide

MDM (Medical Document Management)

An MDM message can be created in relation to or independently of an order. There are 11 different MDM message trigger events. These events always include the status of the document and can also include the accompanying document itself:

  • MDM^T01 - Original Document Notification
  • MDM^T02 - Original Document Notification with Content
  • MDM^T03 - Document Status Change Notification
  • MDM^T04 - Document Status Change Notification with Content
  • MDM^T05 - Document Addendum Notification
  • MDM^T06 - Document Addendum Notification with Content
  • MDM^T07 - Document Edit Notification
  • MDM^T08 - Document Edit Notification with Content
  • MDM^T09 - Document Replacement Notification
  • MDM^T10 - Document Replacement Notification with Content
  • MDM^T11 - Document Cancel Notification

MDM messages are typically used by Radiology departments to communicate provider transcriptions, order information and document contents. These messages either update other healthcare systems to identify available reports in the transcription system and can also provide the documents contents. The most commonly used MDM message is the MDM-T02, similar to an HL7 ORU Result Message, notifying a system of the creation of a document and providing the document contents.

HL7 MDM Diagram

Sample MDM Message

Shown below is an example of an HL7 version 2.3 MDM^T02 message:

MSH|^~\&|MESA_OP|XYZ_HOSPITAL|iFW|ABC_HOSPITAL|20090130123||MDM^T02|20090130123|P|2.3|||NE|
EVN|T02|200901301235|
PID|||||DOE^JOHN||19920115|M||||||||||G83186|005729288| PV1||1|CE||||12345^WILLIS^LAYLA^H|||||||||||
TXA|1|HP^History & Physical|TX|200901151010|||||||||||||DO||AV|
OBX|1|TX|||
OBX|2|TX|||
OBX|3|TX|||
OBX|4|TX|||Name: TEST,TEST
OBX|5|TX|||MR #: 123006
TEST HOSPITAL||||||P|||||| Morrisville, Vermont 05661||||||P||||||
OBX|6|TX|||Physician:JAMES CLEA  DOB:
Date:01/13/09||||||P||||||
Sex: M Age: 19
HISTORY & PHYSICAL||||||P||||||
  Room #:   039A||||||P||||||
Acct. #: G8318||||||P 07/13/1989 Admit
OBX|7|TX|||Physician: KAEDING J Stay Type: I/P D/C||||||P||||||
OBX|8|TX|||Physician:   KEITH P||||||P||||||
OBX|9|TX|||CC: Dizziness and weakness with elevated sugars.||||||P|||
OBX|10|TX|||HPI: This is a 19-year-old man with multiple admissions for poorly controlled||||||P||||||


Segment Description
MSH Message Header. This segment is a mandatory part of an MDM message, and contains information about the message sender and receiver, the date and time that the message was created. This segment is required.
EVN Event Type. Communicates the event that occurred in order for the message to be generated. This segment is a crucial part of the data flow, as it indicates where and when a message is sent based on the type of event. This is a required segment.
PID Patient Identification. An MDM message is a patient-specific message type, and must be linked to a particular patient. Therefore, patient information such as the patient identifier, name, date of birth, etc. must be included in an MDM. This segment is required.
PV1 Patient Visit. Contains information about patient visit details such as servicing facility, attending doctor, and visit ID. This segment is required.
TXA Document Notification. Communicates information specific to a transcribed document as a result of a status change. This segment does not include the document contents and is required.
{OBX} Observation Segment. Contains the document contents. This segment is required and is often repeating segments in an MDM.
[ ] = optional, { } = repeating



For more information on implementing various HL7 message types, please refer to the HL7 Messaging Standard Implementation Guides corresponding to your required version.
